Nexto Logger
Nexto Series
NL717
CE117100 Rev. B
4. Product Features
4.1. General Features
NL717
Digital Inputs 4
Fast Inputs 4
Max. number of high-speed counters 1
Max. number of external interruptions 2
Current Analog Inputs 8
Ethernet TCP / IP interface 1
Max. number of tasks 16
Programming languages
Structured Text (ST)
Ladder Diagram (LD)
Sequential Function Chart (SFC)
Function Block Diagram (FBD)
Continuous Function Chart (CFC)
Online changes Yes
Watchdog Yes
Real-time clock (RTC)
Yes
Resolution of 1 ms, max. variance of 95 seconds per year,
retention time of 20 days.
Status and diagnostic indication
LEDs, web pages and CPU’s internal memory
Isolation
Protective earth to all 1500 Vdc / 1 minute (1000 Vac / 1 minute)
Ethernet to all 1500 Vdc / 1 minute (1000 Vac / 1 minute)
Power Supply/Analog Inputs to all 1500 Vdc / 1 minute (1000 Vac / 1 minute)
Digital Inputs to all 1500 Vdc / 1 minute (1000 Vac / 1 minute)
Maximum power dissipation 15 W
Maximum wire size
0,5 mm
2
(20 AWG) with ferrule
1,5 mm
2
(16 AWG) without ferrule
Minimum wire temperature rating 75
◦
C
Wire materia Copper only
IP level IP 20
Conformal coating of electronic circuits Yes
Operating temperature -20 to 60
◦
C
Storage temperature -25 to 75
◦
C
Operating and storage relative humidity 5% to 96%, non-condensing
Vibration resistance (IEC 60068-2-6, sinus)
7 mm from 5 to 8,4 Hz
2 G from 8,4 to 500 Hz
10 sweeps each axis, 1 octave per minute
Shock resistance (IEC 60068-2-27, half-sine) 15 G for 11 ms, 6 shocks in each of 3 axis
Product dimensions (W x H x D) 215,5 x 98,8 x 34,0 mm
Package dimensions (W x H x D) 270,0 x 102,0 x 40,0 mm
Weight 370 g
Weight with package 430 g
Standards and Certifications
