ALTUS Nexto Series Manual

Nexto Logger
Nexto Series
NL717
CE117100 Rev. B
4.4. Ethernet
Ethernet
Connector Shielded female RJ45
Auto crossover Yes
Maximum cable length 100 m
Cable type UTP or ScTP, category 5
Baud rate 10/100 Mbps
Physical layer 10/100 BASE-TX
Data link layer LLC
Network layer IP
Transport layer TCP (Transmission Control Protocol)
UDP (User Datagram Protocol)
Diagnostic LED (Link/activity)
Table 6: Ethernet Interface Features
4.5. LoRa Radio
LoRa Radio
Connector SMA female
Maximum cable length 10 m (Maximum)
Cable type PigTail
Baud rate 290 bps to 50 kbps
Radio type LoRaWan
Frequency Range 915-928MHz
Network layer LoRaWan
Receiver Sensitivity -140 dBm
Type of Antenna Omnidirectional for outdoor environments
Output Power 27 dBm
Gain 2 dBi
Line-of-Sight Range
3 to 4km in urban areas and 10 to 12km in rural
areas
Table 7: LoRa Radio Features
4.6. SDI-12
SDI-12
Connector 3-pin connector block
Physical interface SDI-12
Power Supply Output 12V
Maximum Current 500 mA
Communication Direction Single data line in half-duplex
Cable length 60m (Maximum)
6
