How to fix Alvarado Turnstiles head that does not turn smoothly?
To resolve a turnstile head that doesn't turn smoothly: * Lubricate: Clean and lubricate the roller bearings. Adjust the hydraulic closure if needed. * Solenoid plunger: Remove any dirt or debris obstructing the solenoid or plunger. * Solenoid bracket: Adjust the solenoid plunger-limiting bracket.
What to do if the horizontal drop arm does not drop during loss of power or fire alarm input in Alvarado EDC Turnstiles?
If the horizontal drop arm on your Alvarado turnstile fails to drop during a power loss or fire alarm, check the following: * Activation signal: Ensure the fire alarm/emergency override system is properly connected to the turnstile control board and is sending a correct activation signal. * Wiring: Check the drop arm solenoid wires and reconnect them if necessary. * Solenoid: Test and replace the drop arm solenoid if it's defective.
Why Alvarado Turnstiles do not unlock?
Several factors can prevent an Alvarado turnstile from unlocking. It could be due to: * Lack of power: For Fail-Lock units, ensure the ON/OFF switch is ON, the fuse is functional (replace if needed), and the LED on the control board is lit. Verify proper voltage (110-120VAC) to the junction box and approximately 10 VAC from the transformer to the control board. * Missing activation signal: Confirm the access control system is correctly connected and sending the right signal to the turnstile control board. * Faulty lock arm spring: Replace any missing, broken, or worn-out springs with Alvarado-specific replacements. * Sticking lock arm: Clean and lubricate the lock arms; adjust the hydraulic closure if required. * Defective solenoid: Test and replace the solenoid if necessary. * ...
What to do if Alvarado EDC do not re-lock?
If an Alvarado turnstile fails to re-lock, several issues could be the cause: * Power supply: For Fail-Safe units, check that the ON/OFF switch is ON, the fuse is intact (replace if needed), and the LED on the control board is illuminated. Ensure proper voltage (110-120VAC) is reaching the junction box and approximately 10 VAC from the transformer to the control board. * Optical sensors: Clear any obstructions from the optical sensors and tighten their mounting screws to ensure proper alignment with the turnstile rotation tabs. * Faulty optical sensor: Repair or replace the optical sensor assembly. * Lock arm spring: Replace any missing, broken, or worn-out springs. Use only springs purchased from Alvarado. * Defective solenoid: Test and replace the solenoid as necessary. * So...
Guidelines for safe installation and operation of the turnstile.
Steps for physically installing the turnstile unit.
Procedure for securing the turnstile to the concrete floor.
Procedures for connecting primary power and access control wiring.
Connecting the turnstile to the power source.
Connecting the turnstile to an access control system.
Diagram and legend for the main control board components.
Detailed explanation of each terminal connection on the control board.
Continued descriptions of control board terminals.
How the turnstile operates in different modes and conditions.
Describes Controlled, Free, and No Passage modes for electric and manual units.
How the turnstile behaves during a power outage (Fail-Lock/Fail-Safe).
General| Brand | Alvarado |
|---|---|
| Model | EDC |
| Category | Turnstiles |
| Language | English |
