IPB-5000B
13. Outline Drawing
13-4
LGK-110 Type, Mitutoyo
Screw for fixing
Thrust Stem
M9.5×0.5
10.6 or more
φ8
14
6.5
73.1
φ12
125.5
31.9
(Stroke)
0
ー0.015
(h7)
