Copyright © 2005 – 2021 AMADA WELD TECH
The engineering designs, drawings and data contained herein are the proprietary work of AMADA
WELD TECH and may not be reproduced, copied, exhibited or otherwise used without the written
authorization of AMADA WELD TECH.
Printed in the United States of America.
Revision Record
Revision EO Date Basis of Revision
A 30000 03/05 None. Original edition (IPB-5000A).
B 46191 01/21 Include displacement monitor in standard unit (IPB-5000B)
FOREWORD
Thank you for purchasing an Amada Weld Tech IPB-5000 Inverter Power Supply. Upon receipt of your
equipment, please thoroughly inspect it for shipping damage prior to its installation. Should there be
any damage, please immediately contact the shipping company to file a claim, and notify us at:
Amada Weld Tech Inc.
1820 South Myrtle Avenue
Monrovia, CA 91016
Telephone: (626) 303-5676
FAX: (626) 358-8048
e-mail: info@amadaweldtech.com
The purpose of this manual is to supply operating and maintenance personnel with the information
needed to properly and safely operate and maintain the IPB-5000 Power Supply. We have made every
effort to ensure that the information in this manual is accurate and adequate. The contents of this factory
manual are subject to change without notice. AMADA WELD TECH is not responsible for any loss or
injury due to improper use of this product.
This manual covers the following models:
→
IPB-5000B-MU/200-240/DISP 1-289-02-02
IPB-5000A-MU/200-240/DISP
→
IPB-5000B-MU/380-480/DISP 1-289-02-03
IPB-5000A-MU/380-480/DISP
The operation of the IPB-5000A is basically the same as the IPB-5000B, except that the Displacement
Monitoring capability is now standard in the IPB-5000B models. This manual can be used as a reference
for both the IPB-5000A and IPB-5000B Power Supply models.
Amada Weld Tech adds an I/O Accessory box on to the rear of the IPB-5000B Power Supply. This
added option has the –MU suffix in the part number. See addendum at the end of this manual for
information about the added –MU option.
