IPB-5000B
9. Timing Chart
9-2
 In the case of DATA OUTPUT at COMM CONTROL,
Communication data output time is included.
Communication Speed
Setting
(COMM SPEED)
Calculation Mode Setting (CALCULATION MODE)
NORMAL FAST
9600bps
330 ms Max. 280 ms Max.
19200bps
275 ms Max. 225 ms Max.
38400bps
245 ms Max. 195 ms Max.
c: Screen Display Time and Start Signal Standby Time
 Screen Display Time
Screen Display Time is the period required from the end of END Signal Output
for screen displaying.
It is 355 ms Max. However, it changes in accordance with the type of screens
as follows.
Display Screen Period
SCHEDULE 205 ms Max.
MONITOR
(The next coming signal makes
the screen display cancelled in
MONITOR Screen.)
0 ms
COMPARATOR 220 ms Max.
ENVELOPE 355 ms Max.
PRECHECK 60 ms Max.
CONTROL 55 ms Max.
STATUS 0 ms
Note) If the takt time is needed to shorten, display the MONITOR or STATUS
screen.
 Start Signal Standby Time
It is the period necessary for opening Start Input Signal.
After Screen Display Time elapsed, it is required to open Start Input for 10ms
or more.
d: CAUTION Output is switched to OFF at the coming input of Start Signal.
