IPB-5000B
10. External Communication Function
10-11
Specified Code
1) Specifying of Weld Sequence (T)
Dimension of “ms” is added to each data.
Specified
Code
Item Range of Setting
Increment/
Decrement
T00 Squeeze Delay Time 0000ms to 999ms 1ms
T01 Squeeze Time 0000ms to 999ms 1ms
T02 Upslope 1 Time 000.0ms to 500.0ms 0.2ms
T03 1st. Weld Time 000.0ms to 500.0ms 0.2ms
T04 Downslope 1 Time 000.0ms to 500.0ms 0.2ms
T05 Cool Time 00.0ms to 99.8ms 0.2ms
T06 Upslope 2 Time 000.0ms to 500.0ms 0.2ms
T07 2nd. Weld Time 000.0ms to 500.0ms 0.2ms
T08 Downslope 2 Time 000.0ms to 500.0ms 0.2ms
T13 Hold Time 000ms to 999ms 1ms
T15 Precheck Weld Time 00.0ms to 10.0ms 0.2ms
2) Setting of Control Current, Voltage and Power (H)
Specified
Code
Item Range of Setting
Increment/
Decrement
H01
WE1
Current
Setting
NORMAL
0.40kA to 4.00kA (IT*-360*6)
0.60kA to 6.00kA (IT*-780*6)
Bracket ( ) shows Transformer.
0.01kA
LOW
0.10kA to 4.00kA (IT*-360*6)
0.15kA to 6.00kA (IT*-780*6)
0.01kA
H02
WE2
Current
Setting
NORMAL
0.40kA to 4.00kA (IT*-360*6)
0.60kA to 6.00kA (IT*-780*6)
0.01kA
LOW
0.10kA to 4.00kA (IT*-360*6)
0.15kA to 6.00kA (IT*-780*6)
0.01kA
H04 WE1 Voltage Setting 0.30V to 9.99V 0.01V
H05 WE2 Voltage Setting 0.30V to 9.99V 0.01V
H06 WE1 Power Setting
00.2kW to 20.0kW (POWER-H) 0.1kW
0.10kW to 9.99kW (POWER-L) 0.01kW
H07 WE2 Power Setting
00.2kW to 20.0kW (POWER-H) 0.1kW
0.10kW to 9.99kW (POWER-L) 0.01kW
H21
Precheck Voltage
Setting
0.00V to 9.99V 0.01V
H50 Transformer Number 1 to 5 1
To Next Page
