IPB-5000B
10. External Communication Function
10-10
 Order Table of Monitor Data (Most Recent Monitor Value)
Order
Output Data
(n=0 to 9)
Contents
0001
n.nn, WE1 Monitor Current (Peak Value)
0002
n.nn, WE2 Monitor Current (Peak Value)
0003
n.nn, WE1 Monitor Voltage (Peak Value)
0004
n.nn, WE2 Monitor Voltage (Peak Value)
0005
nn.n,
(NB1)
WE1 Monitor
Power
POWER-H Constant Power Control
n.nn, POWER-L Constant Power Control
0006
nn.n,
(NB1)
WE2 Monitor
Power
POWER-H Constant Power Control
n.nn, POWER-L Constant Power Control
0007
nn.n,
(NB1)
WE1 Monitor Resistance
0008
nn.n,
(NB1)
WE2 Monitor Resistance
0009
n.nn, Precheck Monitor Current
0010
n.nn, WE1 Monitor Current (RMS Value)
0011
n.nn, WE2 Monitor Current (RMS Value)
0012
n.nn, WE1 Monitor Voltage (RMS Value)
0013
n.nn, WE2 Monitor Voltage (RMS Value)
0014
+/-nn.nnn, Final Displacement
0015
nnn.n, W1 Weld Time
0016
nnn.n, W2 Weld Time
0017
+/-nn.nnn Displacement at detecting Workpiece
NB1: The range between 0.0 and 9.9 is output as [SP]0.0 and [SP]9.9.
