10. External Communication Function
10-9
2) Common Data
Order
Character
String
Item Contents
1 nn,
Selection of Welding
Transformer
01: IT*-360*6
02: IT*-780*6
2 nn, Weld Time
00: Slope Time Excluded
01: Slope Time Included
3 nn,
Selection of Start-up
Condition Stabilizing Time
00: 1ms 01: 5ms
02: 10ms 03: 20ms
4 nn,
Selection of Start-up Input
Signal Type
00: No Self-sustaining
01: Self-sustaining from Weld
Time
02: Self-sustaining from
Squeeze Time
5 nn, Schedule Select Method
00: Closed Circuit of Schedule
Select Terminal (No Parity)
01: Closed Circuit of Schedule
Select Terminal (Parity
Valid)
02: Select on Front Panel
6 nn, End Signal Output Time
00: 10ms 01: 100ms
02: While Start Signal Output
7 nn, Monitor Mode
00: Slope Time Excluded
01: Slope Time Included
8 nn, Transformer Scan Mode
00: OFF 01: ON
02: 1-2 03: 1-3
04: 1-4 05: 1-5
9 nn,
No-current Monitor Neglect
Time
00 to 10 (ms)
10 nn,
Pulse Width Monitor
Neglect Time
00 to 10 (ms)
11 nn, NG Output Mode
00: Open Circuit at NG
01: Closed Circuit at NG
12 nn,
READY Output Mode
Setting
00: ON at Weld ON
01: ON at Power ON
13 nn,
Monitor Value Calculation
Mode
00: High Rate Sampling
01: Low Rate Sampling, Faster
Takt Tim e
14 nn, Minimum Current
00: Settable from 10% of full
scale.
01: Settable from 2.5% of full
scale.
15 nn Displacement polarity
00: Set the force-applying
direction as plus.
01: Set the force-applying
direction as minus.
