IPB-5000B
10. External Communication Function
10-8
(5) Data Code Table
 Order Table of Schedule Data
1) Specific Data in accordance with Schedule No. (Schedule No.: 001 to 127)
Order
Character
String
Item
Range of
Setting
Increment/
Decrement
1 nnnn, Squeeze Time 0000 to 9999 1ms
2 nnn.n, Upslope 1 Time
(NB1)
000.0 to 500.0 0.2ms
3 nnn.n, 1st. Weld Time
(NB1)
000.0 to 500.0 0.2ms
4 nnn.n, Downslope 1 Time
(NB1)
00.0 to 500.0 0.2ms
5 nn.n, Cool Time
(NB1)
00.0 to 99.8 0.2ms
6 nnn.n, Upslope 2 Time
(NB1)
000.0 to 500.0 0.2ms
7 nnn.n, 2nd. Weld Time
(NB1)
000.0 to 500.0 0.2ms
8 nnn.n, Downslope 2 Time
(NB1)
000.0 to 500.0 0.2ms
9 nnn, Hold Time 000 to 999 1ms
10 n.nn,
WE1
Current
Setting
MIN CURR:
NORMAL
0.40 to 6.00
0.01kA
MIN CURR:
LOW
0.10 to 6.00
11 n.nn,
WE2
Current
Setting
MIN CURR:
NORMAL
0.40 to 6.00
0.01kA
MIN CURR:
LOW
0.10 to 6.00
12 n.nn, WE1 Voltage Setting 0.30 to 9.99 0.01V
13 n.nn, WE2 Voltage Setting 0.30 to 9.99 0.01V
14 nn.n,
WE1
Power
Setting
CONTROL:
POWER-H
00.2 to 20.0 0.1kW
CONTROL:
POWER-L
0.10 to 9.99 0.01kW
15 nn.n,
WE2
Power
Setting
CONTROL:
POWER-H
00.2 to 20.0 0.1kW
CONTROL:
POWER-L
0.10 to 9.99 0.01kW
16 n, Transformer No. 1 to 5 ----
17 nn, Control Method in WE1
00 to 04
(NB2)
----
18 nn, Control Method in WE2
19 nnnn Squeeze Delay Time 0000 to 9999 1ms
NB1: You can select whether or not Upslope Time and Downslope Time are
included in Weld Time. If they are not included, the total time of Upslope
Time, Weld Time and Downslope is up to 500 ms.
NB2: 00: CURR, 01: VOLT, 02: COMB, 03: POWER (POWER-H), 04: POWER
(POWER-L)
