IPB-5000B
10. External Communication Function
10-13
4) Reading of Monitor Judgment Results (J)
The function to save judging results is not equipped. Read them after each
welding.
Specified
Code
Item Contents
J00
Judgment Result of Current
Upper/Lower Limit
Judgment Result Data:
‘N’ means OK.
‘L’ means Lower Limit NG.
‘H’ means Upper Limit NG.
J03
Judgment Result of Voltage
Upper/Lower Limit
J06
Judgment Result of Power
Upper/Lower Limit
J12
Judgment Result of
Resistance Upper/Lower
Limit
J18
Judgment Result of Final
Displacement
J55 Judgment Result of Weld Time
J21
Judgment Result of Precheck
Current
Judgment of Weld Workpiece
Setting Status in Precheck:
‘N’ means OK.
‘E’ means NG.
J56
Judgment Result of Work
Detection
J99
Judgment Result (Batch
Output)
Batch output of monitor judgment
result
Batch Output of Monitor Judgment Result (Specified code: J99)
Order Output Data Contents
1 n,
(NB1)
Judgment Result of Current Upper/Lower Limit
2 n,
(NB1)
Judgment Result of Voltage Upper/Lower Limit
3 n,
(NB1)
Judgment Result of Power Upper/Lower Limit
4 n,
(NB1)
Judgment Result of Resistance Upper/Lower Limit
5 n,
(NB2)
Judgment Result of Precheck Current
6 n,
(NB1)
Judgment Result of Final Displacement
7 n,
(NB1)
Judgment Result of Weld Time
8 n
(NB2)
Judgment Result of Work Detection
NB1: Judgment Result Data: ‘N’ means OK, ‘L’ means Lower Limit NG, and ‘H’
means Upper Limit NG.
NB2: Judgment Result Data: ‘N’ means OK, and ‘E’ means NG.
To Next Page
