IPB-5000B
12. Error Codes
12-4
Error
Code
Contents Cause Corrective Action
E-26
DISPLACEMENT
ERROR (HIGH)
Measured displacement is
out of upper limit set at
CONTROL Screen.
*Check workpieces, welder and
welding power supply voltage.
*Check range set at CONTROL
Screen.
E-27
DISPLACEMENT
ERROR (LOW)
Measured displacement is
out of lower limit set at
CONTROL Screen.
*Check workpieces, welder and
welding power supply voltage.
*Check range set at CONTROL
Screen.
E-28
WELD TIME
ERROR (HIGH)
Measured weld time is out
of upper limit set at
CONTROL Screen.
*Check workpieces, welder and
welding power supply voltage.
*Check weld stop setting in
CONTROL Screen and weld stop
input in external interface.
*Check range set at CONTROL
Screen.
E-29
WELD TIME
ERROR (LOW)
Measured weld time is out
of lower limit set at
CONTROL Screen.
*Check workpieces, welder and
welding power supply voltage.
*Check weld stop setting in
CONTROL Screen and weld stop
input in external interface.
*Check range set at CONTROL
Screen.
E-30
WORK DETECT
ERROR
Measured displacement at
end of squeeze is out of
range between lower and
upper limit set at
CONTROL Screen.
*Check workpieces setting and
positioning.
*Check range set at CONTROL
Screen.
CAUTION
If the monitor value is not displayed, the WELD ON/OFF input terminal may be open in
the process of sequence (including the screen display time. See
9.(1) Fundamental
Sequence).
