Opening the door of the electrical enclosure with the power on will
lead to fatal accidents due to electric shock because of a high
voltage.
The electrical enclosure main circuit breaker permits to open the
door only after the power is turned off.
3. Other devices/functions
In order to use the press machine more safely, the following equipment and devices are
furnished as standard features or available as options. Choose them according to the contents
of your work.
3-1. Electrical enclosure main circuit breaker [Standard feature]
Since the slide operates only when the two-hand controls are
pressed simultaneously within 0.5 seconds, dangerous work by
one-hand operation is prevented.
3-2. Simultaneous operation for jogging [Standard feature]
Abnormality of the clutch brake solenoid valve is electrically
sensed and notified.
3-3. Clutch brake solenoid valve with monitoring function [Standard feature]
A normal light curtain stops the press when one light beam is
obstructed, but a light curtain of the 2-light beam obstruction
specification stops the press;
● when two consecutive light beams are obstructed, or
● when only the uppermost or lowermost light beam is obstructed.
The press does not stop even if one light beam is obstructed by the
workpiece.
* This option is suitable for the work where a workpiece is passed
from the light beam plane.
3-4. Light curtain (2-light beam obstruction specification) [Option]
Stops the rotation of the flywheel within a short time.
3-5. Flywheel brake [Option]
10
