8
Installing your refrigerator,
cont.
3. Pull drawer open to full extension.
4. Remove Phillips screw from each side
of rail system. (Some models)
5. Lift top of door to unhook door sup-
ports from rail system. Lift door out to
remove.
To install:
1. Pull both rails out to full extension.
5. With drawer pulled out to full exten-
sion, insert lower basket by aligning
tabs on both sides of lower basket with
notches in rail assembly. Verify that
the basket sides are hooked securely
over the rails.
6. Slide upper basket into freezer. Make
sure that rear of basket hooks behind
rail catch.
3. Lower door into final position.
4. Replace and tighten Phillips screws
that were removed from each side of
rail system.
2. While supporting door, hook door sup-
ports into tabs located on inside of rail.
How to remove and
install the pullout
drawer
To avoid electrical shock which can
cause severe personal injury or death,
disconnect power to refrigerator
before removing doors. After replacing
doors, connect power.
WARNING
To avoid possible injury, product, or
property damage, you will need two
people to perform the following
instructions.
CAUTION
To remove:
1. Pull upper basket out to full extension
and lift out to remove.
To prevent accidental child entrap-
ment or suffocation risk, DO NOT
remove the divider in the top freezer
basket.
DANGER
2. Remove lower basket by pressing
inward on basket sides, then lift
basket.
Press Tab Here
