7
Inner Door/Window Removal
1. Open oven door.
2. Remove screws on hinge side.
3. Beginning at the bottom, carefully insert 1” putty knife between inner and outer door. Pry up on inner
door to release tabs, (2 tabs per side). Work in a clockwise direction to release all tabs, see illustration
below.
1
2
3
4
Tabs
Remove
screws
CAUTION
!
When glass retainer is removed, be careful glass does not fall out of frame.
