COOLING PERFORMANCE DATA
9
MODEL: PCA24C
EXPANDED PERFORMANCE DATA
COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -
S/T 0.65 0.55 0.38 - 0.68 0.57 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.63 0.43 -
Delta T 16 14 10 - 16 14 10 - 16 14 10 - 16 14 11 - 16 14 10 - 15 13 10 -
900 KW 2.05 2.09 2.15 - 2.20 2.25 2.32 - 2.34 2.39 2.46 - 2.46 2.51 2.59 - 2.56 2.62 2.70 - 2.65 2.71 2.80 -
AMPS 9.4 9.6 9.9 - 10.0 10.2 10.5 - 10.7 11.0 11.3 - 11.4 11.6 11.9 - 12.0 12.2 12.5 - 12.6 12.8 13.2 -
HI PR 156 168 178 - 176 189 199 - 200 215 227 - 227 245 258 - 256 275 291 - 283 304 321 -
LO PR 57 60 66 - 60 64 69 - 62 66 72 - 65 69 76 - 68 73 79 - 71 75 82 -
MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -
S/T 0.62 0.52 0.36 - 0.65 0.54 0.37 - 0.66 0.55 0.38 - 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.71 0.60 0.41 -
Delta T 16 14 11 - 17 14 11 - 17 14 11 - 17 14 11 - 16 14 11 - 15 13 10 -
70 800 KW 2.03 2.07 2.14 - 2.18 2.23 2.30 - 2.32 2.37 2.44 - 2.44 2.49 2.57 - 2.54 2.60 2.68 - 2.63 2.68 2.77 -
AMPS 9.4 9.6 9.8 - 10.0 10.2 10.4 - 10.7 10.9 11.2 - 11.3 11.5 11.8 - 11.9 12.1 12.5 - 12.5 12.7 13.1 -
HI PR 155 167 176 - 174 187 197 - 198 213 225 - 225 242 256 - 253 273 288 - 280 301 318 -
LO PR 56 60 65 - 59 63 69 - 62 65 71 - 65 69 75 - 68 72 79 - 70 75 81 -
MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -
S/T 0.60 0.50 0.35 - 0.62 0.52 0.36 - 0.64 0.53 0.37 - 0.66 0.55 0.38 - 0.68 0.57 0.40 - 0.69 0.58 0.40 -
Delta T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 14 11 - 16 14 10 -
700 KW 1.98 2.02 2.09 - 2.13 2.18 2.25 - 2.26 2.31 2.38 - 2.38 2.43 2.51 - 2.48 2.53 2.61 - 2.56 2.62 2.70 -
AMPS 9.2 9.3 9.6 - 9.8 9.9 10.2 - 10.4 10.6 10.9 - 11.0 11.2 11.5 - 11.6 11.8 12.2 - 12.2 12.4 12.8 -
HI PR 150 162 171 - 169 181 192 - 192 206 218 - 218 235 248 - 246 264 279 - 271 292 308 -
LO PR 54 58 63 - 57 61 67 - 60 63 69 - 63 67 73 - 66 70 76 - 68 72 79 -
MBh 23.9 24.6 26.7 28.6 23.4 24.1 26.0 27.9 22.8 23.5 25.4 27.3 22.2 22.9 24.8 26.6 21.1 21.8 23.6 25.3 19.6 20.2 21.8 23.4
S/T 0.74 0.66 0.50 0.32 0.77 0.69 0.52 0.33 0.79 0.71 0.53 0.34 0.81 0.73 0.55 0.35 0.84 0.76 0.57 0.37 0.85 0.76 0.58 0.37
Delta T 18 17 14 9 18 17 14 10 18 17 14 10 19 17 14 10 18 17 14 10 17 16 13 9
900 KW 2.06 2.11 2.17 2.24 2.22 2.27 2.34 2.41 2.36 2.41 2.49 2.57 2.48 2.53 2.61 2.70 2.58 2.64 2.73 2.82 2.67 2.73 2.82 2.91
AMPS 9.5 9.7 9.9 10.2 10.1 10.3 10.6 10.9 10.8 11.0 11.3 11.7 11.4 11.7 12.0 12.4 12.1 12.3 12.7 13.1 12.7 12.9 13.3 13.7
HI PR 158 170 180 187 177 191 201 210 202 217 229 239 230 247 261 272 258 278 294 306 285 307 324 338
LO PR 57 61 66 71 60 64 70 75 63 67 73 78 66 70 77 82 69 74 80 85 71 76 83 88
MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6
22.2
24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7
S/T 0.71 0.63 0.48 0.31 0.73 0.66 0.50 0.32 0.75 0.67 0.51 0.33 0.78
0.69
0.53 0.34 0.81 0.72 0.55 0.35 0.81 0.73 0.55 0.35
Delta T19171410191814101918141019
18
15 10 19 17 14 10 18 16 13 9
75 800 KW 2.05 2.09 2.15 2.22 2.20 2.25 2.32 2.39 2.34 2.39 2.46 2.55 2.46
2.51
2.59 2.68 2.56 2.62 2.70 2.79 2.65 2.71 2.80 2.89
AMPS 9.4 9.6 9.9 10.2 10.0 10.2 10.5 10.8 10.7 11.0 11.3 11.6 11.4
11.6
11.9 12.3 12.0 12.2 12.6 13.0 12.6 12.8 13.2 13.6
HI PR 156 168 178 185 176 189 199 208 200 215 227 237 227
245
258 270 256 275 291 303 283 304 321 335
LO PR 57 60 66 70 60 64 69 74 62 66 72 77 65
69
76 81 68 73 79 85 71 75 82 88
MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.5 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0
S/T 0.68 0.61 0.46 0.30 0.71 0.63 0.48 0.31 0.73 0.65 0.49 0.32 0.75 0.67 0.51 0.33 0.78 0.69 0.53 0.34 0.78 0.70 0.53 0.34
Delta T1918141019181510191815102018151019181510181714 9
700 KW 2.00 2.04 2.10 2.17 2.15 2.19 2.26 2.34 2.28 2.33 2.40 2.48 2.40 2.45 2.53 2.61 2.50 2.55 2.64 2.72 2.58 2.64 2.73 2.82
AMPS 9.2 9.4 9.7 9.9 9.8 10.0 10.3 10.6 10.5 10.7 11.0 11.3 11.1 11.3 11.6 12.0 11.7 11.9 12.3 12.6 12.3 12.5 12.9 13.3
HI PR 152 163 172 180 170 183 193 202 194 208 220 230 221 237 251 261 248 267 282 294 274 295 312 325
LO PR 55 58 64 68 58 62 67 72 60 64 70 75 63 67 74 78 66 71 77 82 69 73 80 85
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
