BLOWER PERFORMANCE DATA
7
Dry Coil Data
Horizontal and Downshot
Horizontal
Downshot
*The shaded area(s) indicates range(s) in excess of maximum external static pressure allowed.
UNIT
STATIC
(in W.C.) CFM WATTS CFM WATTS CFM WATTS CFM WATTS
0.1 840 230 1010 295 1230 385 1660 550
0.2 820 225 990 287 1205 372 1600 530
0.3 800 220 970 280 1180 360 1540 510
0.4 770 210 940 270 1150 345 1480 485
0.5 735 200 905 260 1110 330 1420 460
0.6 700 185 850 250 1060 305 1350 135
0.7 660 170 790 235 1005 290 1280 410
0.8 605 155 700 220 905 275 1205 390
PCA24, 30, 36C**E
High
FAN SPEED
Low Med-Low Med-High
UNIT
STATIC
(in W.C.) CFM WATTS CFM WATTS CFM WATTS
0.2 1540 620 1780 735 2265 1010
0.3 1520 600 1755 705 2160 965
0.4 1495 575 1700 670 2095 925
0.5 1460 555 1640 640 1980 880
0.6 1400 520 1570 600 1885 840
0.7 1335 490 1500 570 1770 795
0.8 1260 450 1400 520 1650 750
PCA42,48,60C**E
LOW MED HIGH
FAN SPEED
UNIT
STATIC
(in W.C.) CFM WATTS CFM WATTS CFM WATTS
0.2 1510 580 1715 665 2040 880
0.3 1475 565 1640 635 1960 855
0.4 1410 535 1580 605 1860 820
0.5 1350 510 1500 570 1770 795
0.6 1280 480 1425 545 1650 755
0.7 1210 450 1335 510 1540 720
0.8 1115 420 1235 475 1430 685
PCA42,48,60C**E
FAN SPEED
LOW MED HIGH
