PACKAGE COOLING SPECIFICATIONS
6
WARNING
All wires and overcurrent protection devices are sized without electric heaters. If heaters are installed
with above wire size, overheating and fire could occur. Refer to heater kit installation manual for wire size
and overcurrent protection device size with heaters installed. Also refer to the unit nameplate.
** IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters. See "Electric Heaters" in the SYSTEM OPERATION
section for additional information.
PCA42C**E PCA48C**E PCA60C**E
COOLING CAPACITY, BTUH 40,500 47,000 58,000
SEER 10.00 10.00 10.00
VOLTAGE (NAMEPLATE)
208/230-60-1 208/230-60-1 208/230-60-1
UNIT AMPS (TOTAL) 24 28.9 34.2
MIN CIRCUIT AMPACITY 28.5 34.3 40.9
MAX OVERCURRENT PROTECTION 45 50 60
TYPE SCROLL SCROLL SCROLL
RATED LOAD AMPS 18 21.8 27.1
LOCKED ROTOR AMPS 103 131 175
HORSEPOWER 1/5 1/3 1/3
RPM 825 1100 1100
FULL LOAD AMPS 1.3 2.4 2.4
LOCKED ROTOR AMPS 2.0 5.8 5.8
BLADE DIAMETER / NUMBER 22" / 4 22" / 4 22" / 4
CFM 2200 3000 3000
FACE AREA (SQ FT.) 12 12 12
NUMBER OF ROWS 1 1 2
FINS PER INCH 20 20 20
HORSEPOWER - NO. OF SPEEDS 3/4 - 3 3/4 - 3 3/4 - 3
FULL LOAD AMPS 4.7 4.7 4.7
LOCKED ROTOR AMPS 12.2 12.2 12.2
MOTOR SPEED TAP - COOLING LOW MEDIUM HIGH
RPM 975 1050 1075
DIAMETER X WIDTH (IN.) 10 X 8 10 X 8 10 X 8
RATED SCFM COOLING 1400 1500 1750
MAX EXTERNAL STATIC PRESS .5" wc .5" wc .5" wc
FACE AREA(SQ. FT.) 4.4 4.4 4.4
NUMBER OF ROWS 4 4 3
FINS PER INCH 14 14 14
FILTER SIZE (SQ. FT.) 4.5 5.0 6.5
DRAIN SIZE 3/4 IN 3/4 IN 3/4 IN
EXPANSION DEVICE ORIFICE ORIFICE ORIFICE
REFRIGERANT CHARGE (R-22) 83 oz. 99 oz. 115 oz.
POWER SUPPLY ENTRANCE SIZE (IN.) 3/4 1-1/4" 3/4 1-1/4" 3/4 1-1/4"
LOW VOLTAGE ENTRANCE SIZE 3/4" 3/4" 3/4"
SHIPPING WEIGHT (LBS.) 363 369 410
OPERATING WEIGHT (LBS.) 347 353 394
ACCESSORIES COMPRESSOR SOUND BLANKET CSB08A CSB08A CSB09A
ROUND TO SQUARE KIT RSDK01A RSDK01A RSDK01A
FREEZE PROTECTION KIT FSK01A FSK01A FSK01A
50°F COMPRESSOR LOCK OUT LOC501A LOC501A LOC501A
PC/PH ROOF CURB PRC06A1 PRC06A1 PRC06A1
COMBINATION ROOF CURB PRC08A1 PRC08A1 PRC08A1
OVER/UNDER TRANSITION PDTROU6A PDTROU6A PDTROU6A
HORIZONTAL DUCT COVER KIT CHK001A CHK001A CHK001A
SINGLE POINT KIT SPK07A SPK08A SPK09A
AMBIENT THERMOSTAT KIT ATK01 ATK01 ATK01
EVAPORATOR
COIL
SPECIFICATIONS
GENERAL
INFORMATION
COOLING
CAPACITY
UNIT
ELECTRICAL
SPECIFICATION
COMPRESSOR
CONDENSER
FAN MOTOR
CONDENSER
FAN
CONDENSER
COIL
EVAPORATOR
BLOWER
EVAPORATOR
BLOWER
MOTOR
