PACKAGE COOLING SPECIFICATIONS
5
WARNING
All wires and overcurrent protection devices are sized without electric heaters. If heaters are installed
with above wire size, overheating and fire could occur. Refer to heater kit installation manual for wire size
and overcurrent protection device size with heaters installed. Also refer to the unit nameplate.
** IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters. See "Electric Heaters" in the SYSTEM OPERATION
section for additional information.
PCA24C**E PCA30C**E PCA36C**E
COOLING CAPACITY, BTUH 24,000 29,600 36,000
SEER 10.0 10.0 10.0
VOLTAGE (NAMEPLATE)
208/230-60-1 208/230-60-1 208/230-60-1
UNIT AMPS (TOTAL) 15.2 18.4 20.2
MIN CIRCUIT AMPACITY 17.9 21.9 24.2
MAX OVERCURRENT PROTECTION 25 35 35
TYPE RECIP RECIP RECIP
RATED LOAD AMPS 11.2 14.4 16.2
LOCKED ROTOR AMPS 61 82 96
HORSEPOWER 1/5 1/5 1/5
RPM 825 825 825
FULL LOAD AMPS 1.3 1.3 1.3
LOCKED ROTOR AMPS 2.0 2.0 2.0
BLADE DIAMETER / NUMBER 22" / 4 22" / 4 22" / 4
CFM 2200 2200 2200
FACE AREA - (SQ. FT.) 8.2 8.2 10.2
NUMBER OF ROWS 1 1 1
FINS PER INCH 20 20 20
HORSEPOWER - NO. OF SPEEDS 1/3 - 4 1/3 - 4 1/3 - 4
FULL LOAD AMPS 2.6 2.6 2.6
LOCKED ROTOR AMPS 4.2 4.2 4.2
MOTOR SPEED TAP - COOLING LOW MED - LOW MED - HIGH
RPM 790 840 960
DIAMETER X WIDTH (IN.) 10 X 8 10 X 8 10 X 8
RATED SCFM COOLING 800 1000 1200
MAX EXTERNAL STATIC PRESS .5" wc .5" wc .5" wc
FACE AREA- (SQ. FT.) 3.2 3.2 3.2
NUMBER OF ROWS 2 2 4
FINS PER INCH 14 14 14
FILTER SIZE - (SQ. FT.) 3 3.4 4
DRAIN SIZE 3/4 IN 3/4 IN 3/4 IN
EXPANSION DEVICE ORIFICE ORIFICE ORIFICE
REFRIGERANT CHARGE R-22 53 oz. 59 oz. 64 oz.
POWER SUPPLY ENTRANCE SIZE (IN.) 3/4 1-1/4 3/4 1-1/4 3/4 1-1/4
LOW VOLTAGE ENTRANCE SIZE 3/4" 3/4" 3/4"
SHIPPING WEIGHT (LBS.) 313 323 333
OPERATING WEIGHT (LBS.) 300 308 320
ACCESSORIES COMPRESSOR SOUND BLANKET CSB04A CSB04A CSB04A
ROUND TO SQUARE KIT RSDK01A RSDK01A RSDK01A
SINGLE POINT KIT SPK04A SPK06A SPK06A
FREEZE PROTECTION KIT FSK01A FSK01A FSK01A
50°F COMPRESSOR LOCK OUT LOC501A LOC501A LOC501A
PC/PH ROOF CURB PRC06A1 PRC06A1 PRC06A1
COMBINATION ROOF CURB PRC08A1 PRC08A1 PRC08A1
OVER/UNDER TRANSITION PDTROU4A PDTROU4A PDTROU4A
HORIZONTAL DUCT COVER KIT CHK001A CHK001A CHK001A
AMBIENT THERMOSTAT KIT ATK01A ATK01A ATK01A
