I. NO ICE/LOW ICE PRODUCTION (cont.)
5. Check Ejector Position (cont)
B. 3:00 Ejector Position
1.
Contamination 1. Replace Ice Maker Module
2.
Cube Jammed (Notice Size of Cube, Hollow?) 2. Un-Jam Cubes
3.
Ice Maker or Refrigerator Not Level 3. Level as Needed
4.
No Power To Ice Maker 4. Trace Power to Determine Discontinuity
5.
Excessive Water-Fill Volume (Large Cubes) 5. Adj. Volume Screw on Module, Change Water Valve or
Lower Pressure
6.
Rack of Cubes Fell Back Into Mold During
Ejection
6. Install New Fill Cup, Check Fill Tube Assy.
C. 4:00 Ejector Position
1.
Contamination 1. Change Ice Maker Module
2.
Thermostat out of calibration 2. Change Out Thermostat, Apply Fresh Coat Of Alumilastic
3.
Open Heater Circuit (Motor Should be
Oscillating)
3. Change Mold/Heater Assy, Apply Fresh Coat Of
Alumilastic
4.
Little/No Alumilastic on Thermostat 4. Apply Fresh Coat Of Alumilastic
5.
Heater Not Staked In Mold 5. Change Mold/Heater Assy, Apply Fresh Coat Of
Alumilastic
6.
Broken Locking Tabs on Vertical Cam 6. Change Module
D. 6:00 Ejector Position
1.
Contamination 1. Change Ice Maker Module
2.
Hollow Cubes 2. Refer to Section III, "Hollow Cubes"
3.
Insufficient Water To Ice Maker, Small Cubes 3. Refer to Section III, "Hollow Cubes"
E. 7:30 Ejector Position
1.
Contamination (Motor Will Not Oscillate) 1. Change Ice Maker Module
2.
Bail Arm Stuck in Ice or Obstructed 2. Remove Obstruction, Replace Ice Maker Module
3.
Pac-Man Cubes (Cubes not formed properly) 3. Un-Jam Unit, Check Fill Cup And Fill Tube Assy.
F. 9:00 Ejector Position
1.
Contamination 5. Change Ice Maker Module
2.
Cube Frozen to Fill Cup or Mold 5. Un-Jam Unit, Install New Fill Cup and Module
Ice Maker Troubleshooting Chart
