RS5290000 Rev. 0 74 April 1998
II. OVER PRODUCTION OF ICE
1. Bail Shut-off Arm Not in Actuator 1. Replace Bail Shut-off Arm in Actuator, Note for Loose
Fit
2. Misformed Bail Shut-off Arm 2. Replace Bail Shut-off Arm
3. Shut-Off Lever Broken or Bypassing Vertical Cam 3. Replace Ice Maker Module
4. Broken Module Actuator 4. Replace Ice Maker Module
III. HOLLOW ICE CUBES
1. Water Fill Volume Too Low 1. Adj. Screw On Module, Clear Water Path Or Change
Water Valve
2. Improper Freezer Air-Flow 2. Re-Direct Air Flow Away from Ice Maker Thermostat
3. Thermostat Out Of Calibration 3. Change Thermostat, Apply Fresh Alumilastic
IV. FLOODING OR ICE SLABS IN BUCKET OR FREEZER
1. Thermostat Out Of Calibration 1. Change Thermostat, Apply Fresh Alumilastic
2. Jammed Cube Stalled In Water-Fill Cycle 2. Remove Cube, Determine Reason For Stall
3. Leaky Water Valve 3. Change Water Valve
4. Fill Volume of Water Valve Excessive 4. Change Water Valve
5. Motor Stalled In Water-Fill Cycle (12:00 Ejector Position) 5. Change Ice Maker Module
6. Contaminated Module 6. Change Ice Maker Module
7. Refrigerator or Ice Maker Not Level 7. Level As Necessary
8. Excessive Water Pressure 8. Lower Water Pressure (20-120 psi) (1.4 - 8.2 bar)
9. Module Shut-Off Switch and Contacts Shorted And
Burned
9. Change Ice Maker Module
10. Broken Locking Tab On Verticle Cam (Stalled in
Waterfill)
10 Change Ice Maker Module
11. Fill-Tube Not Properly Located In Fill Cup 11 Reposition Fill Tube
12. Fill Cup Water Opening Flashed Over/Plugged 12 Change Fill Cup
13. Cubes Fell Over Back Of Ice Maker, Melting Into
Freezer
13 Install New Fill Cup
Ice Maker Troubleshooting Chart
