RS5290000 Rev. 0 76 April 1998
Kit Instructions
Introduction
Read entire manual before installing kit. Confirm all
parts listed are included in kit. If parts are missing,
contact source from whom kit was purchased.
Important
• Mechanical experience is required to install trim kit.
• If unable to solve a problem during installation,
contact source from whom kit was purchased.
Procedure
!
CAUTION
To avoid property damage, protect soft vinyl or
other flooring with cardboard, rugs, or other
protective material.
CAUTION
To avoid personal injury, protect hands and arms.
Trim pieces may have sharp edges.
2. Remove door handles by removing screws.
Description Quantity Part
Number
Description Quantity Part
Number
Toe grille 1 12321806 Bottom trim, refrigerator door 1 10810512
Top trim, freezer door 1 10810311 Door handle 2 12139306
Center trim, freezer door 1 10810603 Black handle insert (top) 2 10953115
Bottom trim, freezer door 1 10810511 Black handle insert (bottom) 2 10953116
Top trim, refrigerator door 1 10810312 Door stop 2 C8972403
Center trim, refrigerator and
freezer door
2 10810403 Installation Instructions 1 10035710
Parts List
HGK300 Black Handle and Toe Grille Kit Installation Instructions
!
Important
Save all screws and reuse in original location.
1. Remove upper and lower handle trim from both
doors by grasping trim along inside edge of door and
pulling foreward. Remove inserts above and below
each handle.
To Next Page
