Kit Instructions
DS18 and DS22 1/4" Trim Kits
Introduction
Included in this kit are trim pieces for installing 1/4 inch
(6 millimeter) decorator panels. Read entire manual
before installing panels. Confirm all parts listed are
included in kit. If parts are missing, contact source from
whom kit was purchased.
Important
• Mechanical experience is required to install trim kit.
• Depending on installer’s knowledge and skill,
installation can take from one to three hours.
• Transfer food to an alternate cooling source. Check
refrigerator warranty certificate for specific
coverage. Warranty does not cover food loss.
• Ensure trim pieces adhere properly by confirming
surfaces are clean, dry and free of adhesive
residue.
• If unable to solve a problem during installation,
contact source from whom kit was purchased.
Decorator Panel Dimensions
Listed below are required height x width dimensions for
decorator panels. Panels are not supplied with this kit
and can be purchased locally.
Caution
To avoid personal injury or property damage,
refrigerator panels should not weigh more than 30
pounds (14 kilograms) and freezer panels should not
weigh more than 15 pounds (7 kilograms).
19 cubic foot Panel Dimensions
Without Dispenser
Refrigerator Door 61 15/16" x 15 13/32"
(1573 mm x 391 mm)
Freezer Door 61 15/16" x 13 1/2"
(1573 mm x 343 mm)
With Dispenser
Refrigerator Door 61 15/16" x 15 13/32"
(1573 mm x 391 mm)
Upper Freezer Door 17 1/4" x 13 1/2"
(438 mm x 343 mm)
Lower Freezer Door 31 13/16" x 13 1/2"
(808 mm x 343 mm)
20, 22, 25 cubic foot Panel Dimensions
Without Dispenser
Refrigerator Door 61 15/16" x 19 5/32"
(1573 mm x 487 mm)
Freezer Door 61 15/16" x 13 1/2"
(1573 mm x 343 mm)
With Dispenser
Refrigerator Door 61 15/16" x 19 5/32"
(1573 mm x 487 mm)
Upper Freezer Door 17 1/4" x 13 1/2"
(438 mm x 343 mm)
Lower Freezer Door 31 13/16" x 13 1/2"
(808 mm x 343 mm)
