INSTALLATION SEMI-
NOTE: Please purchase
special trim for the semi
dealer. See dealer for more details.
The rough wall opening size of the fireplace:
20
-IN WITHIN 2 X 4’S
special trim for the semi
-flush built-
dealer. See dealer for more details.
The rough wall opening size of the fireplace:
Screw locations
Magnetic stone locations
Log set
1. Unscrew 4 screws to take off the trim and get out the log set. (NOTE: Keep hold of the
front glass as it may fall down automatically when the trim is removed.)
W(“) D(“) H(“)
SYM-34(SM-190034-1) 32 7/8 4 16
SYM-42(SM-190042-1) 42 3/4 4 16
SYM-50(SM-190050-1) 50 3/4 4 16
SYM-60(SM-190060-1) 60 3/4 4 16
SYM-74(SM-190074-1) 74 3/4 4 16
SYM-88(SM-190088-1) 88 3/4 4 16
SYM-100(SM-1900100-1) 100 3/4 4 16
To Next Page
