REPLACEMENT PARTS
Ref. Description Quantity
SYM-34 SYM-42 SYM-50 SYM-60
SYM-74 SYM-88 SYM-100
SM-190034-1 SM-190042-1 SM-190050-1 SM-190060-1 SM-190074-1 SM-190088-1 SM-1900100-1
1 Front Glass 1 10701358 10701359 10701346 10701347 10701348 10701363 10701364
2 Trim 1 3200503 3201503 3202503 3203503 3204503 3205503 326503
3 Tray Glass 1 10702224B 10702225B 10702210B 107022
11B 10702212B 10702226B 10702227B
4 Back Glass 1 10702217 10702218 10702219 10702220
10702221 10702222 10702223
5 LED for the Flame Qty Required Based
on Size of Unit
601144 – Qty 2 601144 – Qty 3
601144 – Qty 4
601144 – Qty 5 601144 – Qty 6 601144 – Qty 7 601144 – Qty 8
5 LED for the Tray Qty Required Based
on Size of Unit
601136C–Qty 3 601136C–Qty 1 601136C–Qty 1
601136C–Qty 2 601136C–Qty 2 601136C–Qty 3
601137C-Qty 2 601137C-Qty 3 601137C-Qty 3 601137C-Qty 3
601137C-Qty 4 601137C-Qty 4
6 Flame motor 1 1010501
7 Flicker Assembly 1 3200505B 3236505 3237505 32395
05 3204505B 3205505B 3206505B
8 Fire Box 1
9 Touch Panel 1 10124003 10124003 10124003 10124003
10124003 10124003 10124003
10 Circuit Board 1 10124129 10124129 10124129 10124129 10124129 10124129 10124129
11 Blower & Heater
Assembly
1 602130B 602130B 602130B 602130B 602130B 602130B 602130B
12 Temperature sensor 1 10114001B 10114001B 10114001B 10114001B 10114001B
10114001B 10114001B
13 Signal Receiver 1 3001506B 3001506B 3001506B 300
1506B 3001506B 3001506B 3001506B
14 Remote Control 1 10105501 10105501 10105501 1010
5501 10105501 10105501 10105501
15 Canopy Light Qty Required Based
on Size of Unit
601139B-Qty 1
601139B-Qty 1
601139B-Qty 1 601139B-Qty 1
601139B-Qty 2
601140B-Qty 1
601140B-Qty 1
601140B-Qty 2
601140B-Qty 2 601140B-Qty 3
601140B-Qty 4 601140B-Qty 4
16 WiFi Card 1 212051 212051 212051 212051 212051 2
12051 212051
*Remote Control, Canopy Light & Touch Panel are not
shown in the exploded view
*Items may not appear exactly as illustrated
