Amazone UF 901 - Filling Table for Remaining Spray Area

Using the machine
Formula and answer to Question 1:
Refill amount of water [l] x Concentration [%]
=
Addition of agent [l or kg]
100
(1,200 – 200) [l] x 0.15 [%]
=
1.5 [l or kg]
100
Formula and answer to Question 2:
Quantity of liquid available [l] – Residue [l]
=
Area to be treated [ha]
Water consumption [l/ha]
1,200 [l] (Tank nominal volume) – 20 [l] (Residue)
=
2.36 [ha]
500 [l/ha] Water consumption
11.2.2 Filling table for remaining spray area
To calculate the required re-fill quantity for final filling of the spray
liquid tank use the "Filling table for remaining spray area". Deduct the
residue in the spray line from the calculated re-fill quantity. Refer to
the "Spray lines" section, Seite 46.
The specified re-fill quantities apply for a spray rate of 100 l/ha. For
other spray rates, the re-fill quantity increases by a multiple.
Distance
travelled
[m]
Re-fill quantities [l] for sprayer booms with working widths of
10 m
12 m
15 m
16 m
18 m
20 m
21 m
24 m
10
1
1
2
2
2
2
2
2
20
2
2
3
3
4
4
4
5
30
3
4
5
5
5
6
6
7
40
4
5
6
6
7
8
8
10
50
5
6
8
8
9
10
11
12
60
6
7
9
10
11
12
13
14
70
7
8
11
11
13
14
15
17
80
8
10
12
13
14
16
17
19
90
9
11
14
14
16
18
19
22
100
10
12
15
16
18
20
21
24
200
20
24
30
32
36
40
42
48
300
30
36
45
48
54
60
63
72
400
40
48
60
64
72
80
84
96
500
50
60
75
80
90
100
105
120
UF BAG0012.11 04.19
143
