Amba RADIANT Straight - Assembly Steps; Step 1: Mounting Preparation; Step 2: Attaching the Rack; Step 3: Securing the Unit

Page 2
BEFORE STARTING ASSEMBLY MAKE SURE ALL COMPONENTS LISTED ARE IN THE PACKAGE
DO NOT OVER-TIGHTEN SET SCREW TURN UNIT ON WITH SWITCH
1 2
3
4
22 3/8”
568mm
15 1/4”
388mm
A
B
C
F
D
E
SWITCH
! CAUTION — SURFACE OF UNIT IS HOT WHEN ON !
RADIANT Straight HARDWIRED
INSTALLATION INSTRUCTIONS
