5.3 SIGNAL description:

The ACD 201 / 301 Generates all TimeCodes according to SMPTE /

EBU standards.

TC - IN 0.1 to 5 Volt pp

TC - OUT 1 Volt pp

AATON (ASCII) TTL Level

TUNE OUT TTL Level

5.4 Plug

des

cription:

LEMO 5 PIN

Pin SIGNAL

1 GND Red dot

2 TC- IN 1

3 ASCII I/O

4 TUNE OUT * 2 5

5 TC- OUT

Note: No external DC input as

indicated on slate back panel 3 4

Front view

MINIJACK SOCKET

Pin SIGNAL

TIP TC - OUT

RING TC - IN

SHAFT GND (SHIELD)

We wish you sucessful shooting and in case you have any

questions please don’t hesitate to get in touch with us.
