Ambient ASHP-23 - Installation Options and Piping (Hydronic)

Page 13 of 38
Installation Options and
Piping (Hydronic)
Diagram/Photo Copyright AusGeothermal 2018
3 BAR PRESSURE RELIEF VALVE ½ INCH
COLD WATER FILL ½ INCH MBSP
HYDRONIC RETURN WATER IN 1 INCH
HYDRONIC FLOW WATER OUT 1 INCH
3 BAR PRESSURE RELIEF VALVE ½ INCH
COLD WATER FILL ½ INCH MBSP
HYDRONIC RETURN WATER IN 1 INCH
HYDRONIC FLOW WATER OUT 1 INCH
AMBIENT WITH
BUFFER TANK STORAGE
SENSOR
POCKET
ELECTRICAL SUPPLY
ISOLATOR
SLAB HEATING PUMP CIRCIT 1
SLAB HEATING PUMP CIRCI
T 2
RADIATOR HEATING CIRCIT
FAN COIL HEATING /COOLING
3 BAR PRESSURE RELIEF VALVE ½ INCH
COLD WATER FILL ½ INCH MBSP
HYDRONIC RETURN WATER IN 1 INCH
HYDRONIC FLOW WATER OUT 1 INCH
AMBIENT WITH
INSLAB/SCREED
HEATING/COOLING
ELECTRICAL SUPPLY
ISOLATOR
FLOW TO HYDRONIC IN FLOOR
MANIFOLD
RETURN FROM HYDRONIC IN
FLOOR MANIFOLD
ROOM CONTROLS
TO WIRE BACK TO
AMBIENT EXTERNAL
DIGITAL INPUT
CONTROL BOX
SENSOR POCKET
FOR SUPPLIED
PIPE SENSOR
