Ambirad VPlus40 - Page 21

MODEL
HEAT
INPUT
U TUBE STRAIGHT TUBE
TUBE TYPE
MATERIAL
Btu/h
U20 U40 U60 U80 S10 S20 S30 S40 S50 S60 S70 S80 SE1 SE2
AL.S MS
MIN
DISTANCE
TO BEND
VPLUS40
41,500
0 0 0 0 0 0
TUBE 1 REMAINDER
10
VPLUS80
80,000
0 0 0 0 0 0 0
TUBE 1 REMAINDER
10
VPLUS100
100,000
0 0 0 0 0 0
TUBE 1 REMAINDER
20
VPLUS125
123,500
0 0 0 0 0 0 0
TUBE 1 REMAINDER
20
VPLUS150
150,000
0 0 0 0 0 0 0 0
TUBE 1 REMAINDER
20
VPLUS170
169,000
0 0 0 0 0 0 0 0
TUBE 1 & 2 REMAINDER
30
VPLUS200
200,000
0 0 0 0 0 0 0 0
TUBE 1 & 2 REMAINDER
30
VPLUS225
222,500
0 0 0 0 0 0 0 0
TUBE 1 & 2 REMAINDER
30
OPTIONS
1 All standard units fitted with unvented flue, natural gas, aluminum reflectors and ducted air attachments.
2 Tube length (U20-10ft and S20-20ft)
3 180° bend (U suffix), 1-90° bend (SE1 suffix), 2-90° bends (SE2 suffix) 4 Liquid petroleum gas supply (LP Suffix) 5 Vented design (v suffix) 6 Stainless steel tubes (ST suffix) 7 Stainless steel reflectors (SR suffix) 8 End caps (E suffix)
VPLUS100- U40- LP- V- ST- SR- E
End caps Stainless steel reflectors Stainless steel tubes Vented heater Liquid petroleum gas U tube heater 20ft long (40ft long tubes) 100,000 Btu/h heater
