“VPLUS” SERIES INFRARED GAS HEATER
“S10”
AMBIRAD
SERIES COMBUSTION TUBE REMAINING TUBES REFLECTORS
SC 4” ALUMINISED STL. 4” MILD STEEL ALUMINIUM
ER 4” ALUMINISED STL. 4” MILD STEEL STAINLESS STEEL
11’6½” NOMINAL OVERALL ASSEMBLED LENGTH
FIXED JOINT DETAIL SLIDING JOINT DETAIL
REFLECTOR OVERLAP
2" (50) MINIMUM
C
L
MODEL NUMBER BTU/HR
VPLUS40-S10 41,500
TURBULATOR
TURBULATOR DETAIL
