8b. L-300 AMPLIFIER FEATURES (With Streamer)
1.
1. Bluetooth Antennas (2)
2. Bluetooth Switch
3. Bridge (70V) or Stereo Switch
4. Low Pass Filter (LPF) Switch
5. Gain Knob
6. Clipping/BT Indicator Lights
7. Speaker Output: Right
8. Speaker Output: Left
9. 120V AC Input
10. Fan
11. Bridge (70V) Speaker Output
L+ & R-
12. Line OUT Phoenix Connection
13. Line IN Phoenix Connection
14. USB 5V Power Port to Streamer
15. Streamer
16. RJ45 Internet Hardwire
Connection
17. Speaker Wire Strain Reliefs (2)
18. Weather Resistant Enclosure
19. Mounting Tab
20. Bottom Panel Access Door:
(For easier access, loosen the
2 forward screws on each side &
then pull panel downward)
3.
5.
20.
20.
16.
15.
1.
17.
17.
2.
20.
20.
10.
11.
MANUFACTURED IN CHINA
SERIAL BARCODE
SERIAL NUMBER
BRIDGE (70V)
LEFT + RIGHT -
