9b. POSITIONING & INSTALLING THE SUBWOOFER
I. The S11BP-IG dimensions are 12⁄'' diameter x 23'' high, 17'' diameter
x 18⁄ Canopy
Select a location for the subwoofer. It should be placed as close to the
middle of the speaker system as practical, ideally with half the satellite
speakers on one side and half on the other.
Subwoofer should be positioned away from standing water.
II. For more bass, install the subwoofer near a wall or other solid surface.
III. Make a hole 15’’ diameter x 8’’ deep and insert the subwoofer.
Place subwoofer, as level as possible, not tilted, in the center of hole &
use loose dirt to level the subwoofer, ensuring the subwoofer is not in
direct contact with any large rocks or large empty holes.
Fill remaining space around subwoofer with loose dirt.
Mount the Canopy to the Subwoofer Base. Ensure that all vents under
the Canopy are exposed, allowing a visible space of about 5’’ from the
ground level to the bottom edge of the Canopy.
