Running Wires from the Speaker Amp to the Speakers
I. Connect the LEFT positive conductor from the Speaker Amp to the
LEFT positive (Red Wire) on the 1st satellite speaker. Connect LEFT
negative conductor from the amp to the LEFT negative (Black Wire)
on the satellite speaker.
II. Extend from the LEFT Satellite Speaker to the 2nd Satellite
Speaker.
Connect the LEFT positive to the RED positive wire and the LEFT
negative to the BLACK negative wire on the LEFT Satellite Speaker.
See Diagram 8.
III. Connect the RIGHT positive conductor from the Speaker Amp
to the RIGHT positive (Red Wire) on the satellite speaker. Connect
RIGHT negative conductor from the speaker amp to the RIGHT nega-
tive (Black Wire) on the satellite speaker.
IV. Extend from the RIGHT satellite speaker. Connect the LEFT
positive to the RED positive wire and the RIGHT negative to the
BLACK negative wire on the RIGHT satellite speaker. See Diagram 8.
Make absolutely sure you always connect positive to positive and
negative to negative. And be sure to connect right and left channels
correctly.
If you wire Positive (+) to Negative (-), the system will not perform as
it should. Make all speaker connections and test the system BEFORE
