Ambrell 8310 - Page 41

Technical Information
41
A
MBRELL
801
-
9526
-
00.doc
Precision Induction Heating
24V source & E-stop
Case: (default) jumper ensures that
operation in not interrupted
Case: you include your E-stop switch;
upon switch activation, RF heating is
prevented or interrupted
24V source Signal Outputs
24V is an output from the EASYHEAT. Do Not connect an external voltage supply to
this terminal!
Electrical Touch-pad
Connect to internal solid-state contacts to complete your indicator
signaling (shown);
READY pair closure = Ready
HeatOn pair closure = HeatOn
Fault pair closure = Fault
No polarity to these connections; 1A limit each
Connect your N.C. E-stop (rated 24V @ 3A min.) as shown.
None
Result: Your remote 24Vdc status signals echo EASYHEAT status LEDs; E-stop trip halts
RF power output and equipment operation. Reset E-stop to restart E
ASYHEAT at Home
zone.
24 V
E-Stop
Gnd
+
24 V
E-Stop
Gnd
+
24 V
E-Stop
Gnd
Fault
HeatOn
Ready
+
