Equipment output
Model 3542 4048 5060 7590 8310 units
RF Terminal Power 4.2 4.8 6 9 10
2
kW
RF Deliverable Power 3.5 4.0 5 7.5 8.3
2
kW
AC Line Power 5.2 5.9 7.4 11.2 12.4
2
kVA
Frequency 150 - 400 kHz
RF Coil Current
1
750 A max
1) maximum current reduced under some operating conditions
2) De-rates linearly from 10 kW, 8.3 kW, 12.4 kVA at 205 Vac, to 9.1 kW, 7.6 kW, 11.3 kVA at 187 Vac.
Equipment input (230V models)
Model 3542 4048 5060 7590 8310 units
AC Line Power 5.2 5.9 7.4 11.2 12.4
2
kVA
AC Line Protection 25 30 30 35 35 A
Frequency 50/60 Hz
AC Line Voltage
1
187 - 230 or 230 - 264
Vac, 3

1) Level determined by model; range factory set per order; field selectable; see §3.6 for instructions
2) De-rates linearly from 12.4 kVA at 205 Vac, to 11.3 kVA at 187 Vac.
The equipment requires a connection to earth ground and does not make use of neutral.
Failure to connect earth (safety) ground will result in a potentially hazardous condition. Do not
omit this step!
Electrical installations must be made by qualified personnel and must conform to applicable
safety codes.
Do not connect 230V models to 440V mains; damage and hazard will result!
