Footswitch
You can attach an optional footswitch to your EASYHEAT, enabling you to toggle HeatOn
remotely. In the first example, heating occurs only while you depress the switch; in the
second, the footswitch starts a timed cycle
Continuous Touch panel
STOPGnd: Jumper retained
STARTGnd: N.O. contact
►System Options
Start From
►Rear Panel
Start Type
►1 button
Timer Touch panel
STOPGnd: Jumper retained
STARTGnd: N.O. contact
►System Options
Start From
►Rear Panel
Start Type
►2 button
 Adjust Timer for desired
duration
 Depress footswitch to start
timer
