User’s manual
EN
TECHNICAL INFORMATION
TECHNICAL SPECIFICATIONS
Description
Model
7060DE0
Version A B
Maximum recommended surface that can be mowed
Working capacity ( -20%(*)) m
2
(sq ' ) 200 ( 2150' ) 400 ( 4300' )
Daily cycles required to cover the
maximum area (*)
2 in case of complex gardens and gardens with fast-growing grass
Features
Dimensions (W x H x D) mm 409x199x335
Robot weight (incl. battery) kg 8,3 8,6
Cutting height (Min-Max) mm (") 42-48 ( 1.65-1,88 " )
Diameter of blade with 4 cutting
edges
mm (") 250 ( 9,84 " )
Drive system 4WD
Cutting blade speed RPM
4000 cutting
3000 maintenance
Ground speed Metres / Minute 18 (59 ')
Maximum recommended slope
managed (*)
%
50%. Allowable, based on the lawn conditions and accessories
installed.
40%. maximum managed and recommended in conditions of a
trimmed lawn.
Ambient operating temperature Max °C
ROBOT -10°(14 F.) (Min) +42° (107 F.) (Max)
BATTERY CHARGER -10°(14 F.) (Min) +40° (104 F.) (Max)
Measured noise level dB(A) 65
Water protection class IP
ROBOT: IPx3
BATTERY CHARGER: IPx4
Electrical features
Power supply unit (for lithium battery)
Mean Well OWA-60E-30ZCT
Input: 100 - 240 V~; 1.2 A;
50/60 Hz; Class 2
Output: 29.4 V
; 2.0 A;
Type of accumulator and charging batteries
Rechargeable Lithium-Ion Battery 25.9V - 5.0Ah 25,9 - 7.5Ah
Battery charger 29.4 Vcc - 2.0 Ah
Average recharging time hh:mm 3:00 4:30
Average mowing duration after a full
charge cycle (*)
hh:mm 2:00 3:00
(*) Depends on the condition of the grass, lawn and the complexity of the mowing area.
