AMCOT ST SERIES FIBERGLASS COOLING TOWER
- 28 -
Pipe Connection Chart:
MODEL
INLET
OUTLET
MAKEUP
QUICK FILL
OVERFLOW
DRAIN
ST-3
1 1/2"
1 1/2"
1/2"
-
1"
3/4"
ST-H-3
1 1/2"
1 1/2"
1/2"
1"
3/4"
ST-5
1 1/2"
1 1/2"
1/2"
-
1"
3/4"
ST-H-5
1 1/2"
1 1/2"
1/2"
1"
3/4"
ST-8
1 1/2"
1 1/2"
1/2"
-
1"
3/4"
ST-H-8
1 1/2"
1 1/2"
1/2"
1"
3/4"
ST-10
1 1/2"
1 1/2"
1/2"
-
1"
3/4"
ST-H-10
1 1/2"
1 1/2"
1/2"
1"
3/4"
ST-15
2"
2"
1/2"
-
1"
1"
ST-H-15
2"
2"
1/2"
1"
1"
ST-20-1
2"
2"
1/2"
-
1"
1"
ST-H-20-1
2"
2"
1/2"
1"
1"
ST-20-3
2"
2"
1/2"
-
1"
1"
ST-H-20-3
2"
2"
1/2"
1"
1"
ST-25
2 1/2"
2 1/2"
1/2"
-
1"
1"
ST-30
2 1/2"
2 1/2"
1/2"
-
1"
1"
ST-40
2 1/2"
2 1/2"
3/4"
-
1"
1"
ST-50
3"
3"
3/4"
-
1"
1"
ST-60
3"
3"
3/4"
-
1"
1"
ST-70
4"
4"
3/4"
-
1"
1"
ST-80
4"
4"
3/4"
-
1"
1"
ST-100
4"
4"
1"
-
1"
1"
ST-125
5"
5"
1"
-
2"
1"
ST-150
5"
5"
1"
-
2"
2"
ST-175
5"
5"
1"
-
2"
2"
ST-200
6"
6"
1 1/4"
1 1/4"
2"
2"
ST-225
6"
6"
1 1/4"
1 1/4"
2"
2"
ST-250
8"
8"
1 1/4"
1 1/4"
2"
2"
ST-300
8"
8"
1 1/4"
1 1/4"
2"
2"
ST-350
8"
8"
1 1/4"
1 1/4"
2"
2"
ST-400
8"
8"
2"
2"
4"
2"
ST-500
10"
10"
2"
2"
4"
2"
ST-600
10"
10"
2"
2"
4"
2"
ST-700
10"
10"
2"
2"
4"
2"
ST-800
12"
12"
2"
2"
4"
3"
ST-1000
12"
12"
2"
2"
4"
3"
ST-1250
12"
12"
2 1/2"
2 1/2"
4"
3"
ST-1500
14"
14"
2 1/2"
2 1/2"
4"
3"
 Inlet/Outlet Connections 3” and less are Female Pipe Thread.
 Inlet/Outlet Connections 4” and larger are 125 pound Flange Type.
 Make-up & Quick Fill connections are Male Pipe Thread.
 Overflow & Drain are Female Pipe Thread.
