AMD 740G User Manual

3
3
1-2 Specification
Spec Description
Design
z PCB size:22.5cm*17.1cm (MA3-740GSMD2 and MA3-740GSM);
22.5cm*17.6cm (MA3-760GSMD2G)
Chipset
z AMD 740G or AMD 760G North Bridge Chipset
z AMD SB710 South Bridge Chipset
CPU Socket
z Support Socket AM3 CPU under the 95W: Phenom II x 6
；
Phenom II x
4
；
Phenom II x 3
；
Phenom II x2
；
Athlon II x4
；
Athlon II x3
；
Athlon II
x2
；
Sempron CPU
z Support AM2 CPU under 65W and AM2+ CPU under 95W (optional
for Model MA3-740GD2 and MA3-760GSMD2G only)
* For more CPU support information please visit our official website.
Memory Socket
z 240-pin DDRIII module slot x 2 support 2pcs DRIII 800/DDRIII
1066/DDRIII 1333/DDRIII 1600 modules expandable to 8GB(optional
for MA3-740GSM model only)
z 240-pin DDRII Module slot x 2 support 2pcs DDRII 400/DDRII
533/DDRII 667/DDRII 800 modules expandable to 8GB (optional for
Model MA3-740GD2 and MA3-760GSMD2G only)
z Dual channel supported
Expansion Slot
z 1 pcs PCI-Express x16 by 16 lane
z 1pcs 32-bit PCI slot
Integrate IDE and
Serial ATA2 RAID
z One IDE controllers support PCI Bus Mastering, ATA PIO/DMA and
the ULTRA DMA 33/66/100/133 functions that deliver the data
transfer rate up to 133 MB/s for one IDE Devices and for two Serial
ATA2 ports providing 300 MB/sec data transfer rate with RAID 0, 1,
10, JBOD functions
Integrated LAN Chip
z PCI-E Megabit LAN chip(MA3-740GSMD2 and MA3-740GSM).
z PCI-E Gigabit LAN chip (MA3-760GSMD2G)
z Support Fast Ethernet LAN function of providing 10/100Mbps
(MA3-740GSMD2 and MA3-740GSM) or 10 / 100 / 1000 Mbps
(MA3-760GSMD2G) data transfer rate
6 CH-Audio
z Realtek ALC662 HD Audio 6-channel Audio Codec integrated
z Audio driver and utility included
BIOS
z AMI 8MB SPI Flash ROM BIOS
Multi I/O
z PS/2 keyboard and PS/2 mouse connectors
z VGA Connector x1
z USB 2.0 port x4 and header x1
z RJ-45 LAN Connector x1
z Audio connector x1
z Hard disk driver connector x1/ SATA connector x 2
z Serial Port header x1
z HDMI-SPDIF header x1
1-3 Item Checklist
5
AMD740G/760G Platform Processor Chipset based motherboard
5
DVD for motherboard utilities
5
User’s Manual
5
SATA Cable
5
Back Shied
