AMD ATHLON 8

Chapter 11 Pin Descriptions 61
25175H—March 2003 AMD Athlon™ XP Processor Model 8 Data Sheet
Preliminary Information
SD#37 SDATA[37]# C23
SD#38 SDATA[38]# C27
SD#39 SDATA[39]# A23
SD#40 SDATA[40]# A35
SD#41 SDATA[41]# C35
SD#42 SDATA[42]# C33
SD#43 SDATA[43]# C31
SD#44 SDATA[44]# A29
SD#45 SDATA[45]# C29
SD#46 SDATA[46]# E23
SD#47 SDATA[47]# C25
SD#48 SDATA[48]# E17
SD#49 SDATA[49]# E13
SD#50 SDATA[50]# E11
SD#51 SDATA[51]# C15
SD#52 SDATA[52]# E9
SD#53 SDATA[53]# A13
SD#54 SDATA[54]# C9
SD#55 SDATA[55]# A9
SD#56 SDATA[56]# C21
SD#57 SDATA[57]# A21
SD#58 SDATA[58]# E19
SD#59 SDATA[59]# C19
SD#60 SDATA[60]# C17
SD#61 SDATA[61]# A11
SD#62 SDATA[62]# A17
SD#63 SDATA[63]# A15
SDIC#0 SDATAINCLK[0]# W33
SDIC#1 SDATAINCLK[1]# J35
SDIC#2 SDATAINCLK[2]# E27
SDIC#3 SDATAINCLK[3]# E15
SDINV# SDATAINVALID# AN33
SDOC#0 SDATAOUTCLK[0]# AE35
SDOC#1 SDATAOUTCLK[1]# C37
Table 24. Pin Name Abbreviations (continued)
Abbreviation Full Name Pin
SDOC#2 SDATAOUTCLK[2]# A33
SDOC#3 SDATAOUTCLK[3]# C11
SDOV# SDATAOUTVALID# AL31
SFILLV# SFILLVALID# AJ31
SMI# AN5
STPC# STPCLK# AC1
TCK Q1
TDI U1
TDO U5
THDA THERMDA S7
THDC THERMDC U7
TMS Q3
TRST# U3
VCC
V
CC_CORE
B4
VCC
V
CC_CORE
B8
VCC
V
CC_CORE
B12
VCC
V
CC_CORE
B16
VCC
V
CC_CORE
B20
VCC
V
CC_CORE
B24
VCC
V
CC_CORE
B28
VCC
V
CC_CORE
B32
VCC
V
CC_CORE
B36
VCC
V
CC_CORE
D2
VCC
V
CC_CORE
D4
VCC
V
CC_CORE
D8
VCC
V
CC_CORE
D12
VCC
V
CC_CORE
D16
VCC
V
CC_CORE
D20
VCC
V
CC_CORE
D24
VCC
V
CC_CORE
D28
VCC
V
CC_CORE
D32
VCC
V
CC_CORE
F12
VCC
V
CC_CORE
F16
VCC
V
CC_CORE
F20
Table 24. Pin Name Abbreviations (continued)
Abbreviation Full Name Pin
