12 Ordering Information
This section provides the ordering information for the
AMD Athlon™ XP processor model 8.
Standard AMD Athlon™ XP Processor Model 8 Products
AMD standard products are available in several operating
ranges. The ordering part numbers (OPN) are formed by a
combination of the elements, as shown in Figure 18.
Figure 18. OPN Example for the AMD Athlon™ XP Processor Model 8
D K V 3
OPN
1
Advanced Front-Side Bus (FSB): C = 266, D = 333
Size of L2 Cache: 3 = 256 Kbytes
Die Temperature: T = 90°C, V = 85°C
Operating Voltage: L = 1.50 V, U = 1.60 V, K = 1.65 V
Package Type: D = OPGA
Model Number: 1600 operates at 1400 MHz
2
,
1700 at 1467 MHz
2
,
1800 at 1533 MHz
2
,
1900 at 1600 MHz
2
,
2000
at 1667 MHz
2
,
2100 at 1733 MHz
2
,
2200 at 1800 MHz
2
,
2400 at 2000 MHz
2
,
2600 at 2083 MHz
3
or 2133 MHz
2
,
2700 at 2167 MHz
3
Maximum Power: A = Desktop Processor
Architecture Segment: AXD = AMD Athlon™ XP Processor Model 8 with
QuantiSpeed™ Architecture for Desktop Products
AXD A D2700
Notes:
1. Spaces are added to the number shown above for viewing clarity only.
2. This processor is available only with a 266 advanced FSB.
3. This processor is available only with a 333 advanced FSB.
