AMD ATHLON 8

Chapter 11 Pin Descriptions 67
25175H—March 2003 AMD Athlon™ XP Processor Model 8 Data Sheet
Preliminary Information
D10 VSS ---
D12
V
CC_CORE
---
D14 VSS ---
D16
V
CC_CORE
---
D18 VSS ---
D20
V
CC_CORE
---
D22VSS ---
D24
V
CC_CORE
---
D26VSS ---
D28
V
CC_CORE
---
D30VSS ---
D32
V
CC_CORE
---
D34VSS ---
D36VSS ---
E1 SADDOUT[11]# P O P
E3 SADDOUTCLK# P O G
E5 SADDOUT[4]# P O P
E7 SADDOUT[6]# P O G
E9 SDATA[52]# P B P
E11 SDATA[50]# P B P
E13 SDATA[49]# P B G
E15 SDATAINCLK[3]# P I G
E17 SDATA[48]# P B P
E19 SDATA[58]# P B G
E21 SDATA[36]# P B P
E23 SDATA[46]# P B P
E25 NC Pin page 78 - - -
E27 SDATAINCLK[2]# P I G
E29 SDATA[33]# P B P
E31 SDATA[32]# P B P
Table 25. Cross-Reference by Pin Location
Pin Name Description L P R
E33 NC Pin page 78 - - -
E35 SDATA[31]# P B P
E37 SDATA[22]# P B G
F2 VSS ---
F4 VSS ---
F6 VSS ---
F8 NC Pin page 78 - - -
F10 VSS ---
F12
V
CC_CORE
---
F14 VSS ---
F16
V
CC_CORE
---
F18 VSS ---
F20
V
CC_CORE
---
F22 VSS ---
F24
V
CC_CORE
---
F26 VSS ---
F28
V
CC_CORE
---
F30 NC Pin page 78 - - -
F32
V
CC_CORE
---
F34
V
CC_CORE
---
F36
V
CC_CORE
---
G1 SADDOUT[10]# P O P
G3 SADDOUT[14]# P O G
G5 SADDOUT[13]# P O G
G7 Key Pin page 78 - - -
G9 Key Pin page 78 - - -
G11 NC Pin page 78 - - -
G13 NC Pin page 78 - - -
G15 Key Pin page 78 - - -
G17 Key Pin page 78 - - -
Table 25. Cross-Reference by Pin Location
Pin Name Description L P R
(continued)
