Caution:

Static electricity can seriously damage computer components. Discharge

your body's static electricity by touching the power supply case or the metal

surface of the computer chassis before you touch any components inside the

computer's case to avoid damaging them.

4. Unscrew or unfasten and remove any existing graphics card from the computer,

if necessary.

Warning:

Some graphics cards can get hot while operating. Wait approximately five

minutes after turning off the computer before touching the card.

5. Locate the appropriate bus slot and, if necessary, remove the corresponding

metal backplate cover(s). Make sure all internal cables are clear of the slot.

Note: If you cannot find a bus slot to match the card, you need a graphics card

with the correct bus to match the motherboard.

6. Align the graphics card with the slot.

7. Make sure that all cables are moved out of the way and press the graphics card

firmly in the slot until it is fully seated.

8. Fasten the graphics card securely to the back panel.

9. If your card requires supplementary power and must be connected directly to

the power supply, locate the appropriate power connector cable(s) from the

power supply and connect it (or them) to the graphics card's power connector(s).

The location of power connections may vary between models. They can be

located on either the side or top of the card.

Tip: Before installing a card that requires a supplementary power connection,

make sure your existing power supply has the required power connectors

available.

10. If needed, install the second graphics card in the same manner as the first.

Note: Graphics cards must be separated by at least one empty expansion slot

for proper air flow.

4 Hardware and Software Installation
