INSTALLATION AND OPERATING INSTRUCTIONS
72-0113 08-03-18 4211-149 7014363 314 SYRA 77 D
Page 6
SECTION 3: INSTALLATION PREMIUM/A60 CONTROL (1601-33 or 1601-33-1)
CONTROL OPTIONS: This heater has two different control options. A Premium/A60 Control (1601-33 or 1601-33-1) or
Trend/A30 Control (1601-31 or 1601-31-1) can be connected to the heater. This heater can support both at the same time as
another option.
INSTALLATION ROUGH IN: Place the control inside or outside the sauna room. If the control is installed inside a sauna room,
the top of the unit cannot be higher than 48 inches above oor. Maximum control cable length is 100 feet.
String the provided low voltage control cable through 1” holes in the wall studs or ceiling joists from the control location to the
heater. Do not use staples to secure the low voltage cable, it may damage the cable!
Plug the control cable into the control and TEST the control BEFORE mounting!!
Premium/A60 Control can be SURFACE MOUNTED or RECESSED MOUNTED.
SURFACE MOUNTING CONTROL: After testing is complete, CLEAN the mounting surface to ensure it is free from dust.
Remove the adhesive tape from the back of the control, push any excess cable into wall cavity and press the control to the
mounting surface. (Do not use the Mounting Box or Trim Ring for this installation.)
RECESS MOUNTING: See page 9 for information.
For troubleshooting or service questions call 1-888-780-4427 and ask to speak with service. Prior to calling,
please have the Model and Type number available. You may also email us at
techsupport@tyloheloinc.com
SECTION 4: TROUBLESHOOTING
Trim Ring
Control
Recess Mounting Box
