©American Audio® - www.americanaudio.com - VX Series™ Power Amplifier User Manual Page 15
TYPICAL MONO BRIDGE SET-UP
SPEAKERS
8 OHM MINIMUM
TYPICAL STEREO OUTPUT CONNECTIONS
SPEAKERS
4 OHM MINIMUM
SPEAKERS
4 OHM MINIMUM
Use Channel 1 Input Only (XLR Jack)
X
Use Speakon or Banana Jacks
Use the two positive binding post
termainals (red) for speaker output.
Figure 14
Figure 13
