TripleFlex 9 Channel Mode - DMX Traits
Channel Value Function
1 0 - 255 MIRROR 1 0˚ - 45˚
2 COLOR MACROS LED 1
0 - 7 OFF
8 - 15 COLOR 1
16 - 23 COLOR 2
24 - 31 COLOR 3
32 - 39 COLOR 4
40 - 47 COLOR 5
48 - 55 COLOR 6
56 - 63 COLOR 7
64 - 71 COLOR 8
72 - 79 COLOR 9
80 - 87 COLOR 10
88 - 95 COLOR 11
96 - 103 COLOR 12
104 - 111 COLOR 13
112 - 119 COLOR 14
120 - 127 COLOR 15
128 - 135 COLOR 16
136 - 143 COLOR 17
144 - 151 COLOR 18
152 - 159 COLOR 19
160 - 167 COLOR 20
168 - 175 COLOR 21
176 - 183 COLOR 22
184 - 191 COLOR 23
192 - 199 COLOR 24
200 - 207 COLOR 25
208 - 215 COLOR 26
216 - 223 COLOR 27
224 - 231 COLOR 28
232 - 239 COLOR 29
240 - 247 COLOR 30
248 - 255 COLOR 31
TripleFlex 4 Channel Mode - DMX Traits
Channel Value Function
1 CHASES
0 - 15 OFF
16 - 31 CHASE 1
32 - 47 CHASE 2
48 - 63 CHASE 3
64 - 79 CHASE 4
80 - 95 CHASE 5
96 - 111 CHASE 6
112 - 127 CHASE 7
128 - 143 CHASE 8
144 - 159 CHASE 9
160 - 175 CHASE 10
176 - 191 CHASE 11
192 - 207 CHASE 12
208 - 223 CHASE 13
224 - 239 CHASE 14
240 - 255 SOUND ACTIVE
2 CHASE SPEED
0 - 249 SLOW - FAST
250 - 255 SOUND ACTIVE
3 MOVEMENT
0 - 7 NO MOVEMENT
8 - 38 MOVEMENT 1
39 - 69 MOVEMENT 2
70 - 100 MOVEMENT 3
101 - 131 MOVEMENT 4
132 - 162 MOVEMENT 5
163 - 193 MOVEMENT 6
194 - 224 MOVEMENT 7
225 - 255 MOVEMENT 8
4 STROBING
0 - 7 ON
8 - 255 STROBING SLOW - FAST
