IC Controller Operations Manual
1.3 Door Frame Heater and Window Heater Control
IC controller switches on the door frame heater and the window heater (if so equipped) when the air temperature
drops below the preset threshold of 45oF and then cycle them on and off based on a time cycle. On coolers, by
default, the heaters stay on for 35% of a 6-minute cycle and then will stay off for 65%, the cycle will repeat. On
freezers, by default, controller keeps the heaters on until the temperature of the cabinet goes above 45˚F. The alarm’s
set points and delay times are fully programmable to user’s needs.
Default set points:
Heaters On (Pr) Heaters Off
Heaters Switched On Below Temp:
(tP)
Cooler 30% of 6-minute cycle 65% of 6-minute cycle
45˚FFreezer 100% of 6-minute cycle 0% of 6-minute cycle
Beer Cooler 65% of a 6-minute cycle 35% of a 6-minute cycle
1.4 Electronically Controlled Light Switch and Automatic Light Off
The cabinet light can be switched on and off from the IC controller. The integrated light button is equipped with an
LED light to display the ON/OFF status of the light.
The Automatic Light Off feature of IC enables the user to save energy. The amount of time the light will stay on can
be set from 1 minute to 60 minutes or can be set for manual shut off only. As default, the automatic light off feature is
disabled.
Back-to-back light control is provided as an optional feature.
