STEP5
UNLOCK
LOCK
APRETAR
DESAPRETAR
OUVRIR
SERRER
A
A
G
G
E
I
J
11
5.1 Attach assembled (A), (I) and (J) to (G) as illustrated.
5.2 Attach (E) to (A) as illustrated.
