Ameriwood HOME TYLER 4947013COM - 7

Part List
ameriwoodhome.com
7
Hardware Bag Reference number:
24947013COM0GO
Actual Size
×20 ×20
×19
×2
CAM LOCK
TGO2100
WOOD DOWEL
TGO2900
SCREW
TGO1013
Ø3 X 12mm
×21
SCREW
TGO1301
Ø4.2 X 45MM
Ø8 x 30mm
Ø15 x 10mm
1 2
4
6 7
×33
Ø6 x 25mm
CAM BOLT
TGO2001
3
×22
WOOD DOWEL
TGO2903
Ø6 x 30mm
5
Not Actual Size
×2
9
WALL ANCHOR
TGO6501
Ø6 x 30mm
Tube
You
Ø4 x 38mm
SCREW
TGO1319
×18
Ø5 x 38mm
SCREW
TGO1320
